15 kontaktų D-sub įvesties ir išvesties jungtys - 1
Aprašymas - "16 Channels Penta-brid 1080N/720P Compact 1U 1HDD WizSense Digital Video Recorder > H.265+/H.265 dual-stream video compression > Supports Full-channel AI-Coding > Supports HDCVI/AHD/TVI/CVBS/IP video inputs > Max 18 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps Incoming Bandwidth > Long transmission distance over coax cable > Up to 8 channels video stream (analog channel) SMD Plus
DVR tipas - 16 kanalų
Eksploatavimo sąlygos - Darbinė santykinė drėgmė (H-H) - 10 - 90%
Eksploatavimo sąlygos - Darbinė temperatūra (T-T) - -10 - 45 °C
Eksploatavimo sąlygos - Laikymo temperatūra (T-T) - -20 - 70 °C
Eksploatavimo sąlygos - Sandėliavimo santykinė drėgmė (H-H) - 0 - 90%
Fotoaparato suderinamumas - HDCVI 1080P/HDCVI 720P
Garantija - 36 mėnesiai
GarantijaInformacija -
Garso įvesties ir išvesties jungtys - 1
Garso įvesties ir išvesties jungtys - 1
GTIN - 6939554919299
Hard drive - Maximum HDD capacity - 6 TB
HDMI įvesties ir išvesties jungtys - 1
Kategorija - Skaitmeniniai vaizdo įrašymo įrenginiai (DVR)
Kategorijos kodas - STD
Kietasis diskas - HDD sąsaja - SATA, SATA II, SATA III
Kietasis diskas - palaikomų kietųjų diskų skaičius - 1
LongDesc - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, Cooper Series featuring SMD Plus to benefit customers from AI upgrade. The series are designated to reduce false-alarm rates and human surveillance costs, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.SMD PlusSMD Plus, referred to as Smart Motion Detection Plus, which is an upgrading version of SMD that greatly improves the alarm accuracy by loading deep-learning algorithm. It analyzes person and vehicle shapes based on motion detection and send alarms only when person and vehicle intrudes.*SMD Plus takes effect when SMD or IVS&SMD is selected in AI Mode.AI CodingCompared with H.265, AI codec can reduce up to 50% bit rate and storage requirements while have no loss of decoding compatibility, providing clear human and vehicle details.Smart H.265+Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras.HDCVI/AHD/TVI/CVBS Auto-detectThe XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient.High Definition Camera InputThe XVR supports up to 1080p HDCVI camera and 6MP IP camera input.Coaxial Audio/Upgrade/AlarmThe integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation.Long Distance TransmissionThe HDCVI system supports long distance transmission over coaxial cable and UTP, max. 700 m for 4K/4MP, 800 m for 1080p and 1200 m for 720p.
LongProductName - 16 channels, BNC, 1080p, RCA, HDMI, VGA, RJ-45, USB 2.0, SATA, DC 12V, 1U, 260x231.4x47.6 mm
LongSummaryDescription - Dahua Technology XVR1B16-I. Product colour: Black, Maximum video resolution: 1920 x 1080 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Video input channels: 16 channels. Ethernet interface type: Fast Ethernet, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm..., Number of users: 128 user(s). HDD interface: SATA, SATA II, SATA III, Maximum HDD capacity: 6 TB. DC voltage: 12 V, Power consumption (typical): 10 W
Maitinimas - Energijos suvartojimas (tipinis) - 10 W
Maitinimas - nuolatinė įtampa - 12 V
Maitinimo reikalavimai - 12 VDC, 2 A
Matmenys - 260.0 × 231.4 × 47.6 mm
Modelis - XVR1B16-I
Našumas - Bitų perdavimo sparta - 4096 Kbit/s
Našumas - Didžiausia vaizdo įrašų skiriamoji geba - 1920 x 1080 pikselių
Našumas - Vaizdo įrašų glaudinimo formatai - H.264, H.264+, H.265, H.265+, H.265+, H.265+
Pardavėjo interneto svetainė - www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Recorders/Cooper-I-Series/XVR1B16-I
Pavadinimas - Dahua Technology XVR1B16-I Black
Performance - Playback resolutions supported - 1920 × 1080, 1280 × 1024, 1280 × 720
Performance - Video capturing speed - 30 kadrų per sekundę
Performance - Video streaming - Taip
Pilnas aprašymas Linija - 16 Channel|Camera Compatibility HDCVI 720P/HDCVI 1080P|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|12 VDC, 2 A|Colour Black
Prekės ženklas - "Dahua" technologija
Prekės ženklo dalies kodas - DH-XVR1B16-I
Prievadai ir sąsajos - BNC įvesties prievadai - 16
Prievadai ir sąsajos - Garso išvestis - 1
Prievadai ir sąsajos - Garso įvestis - 1
Prievadai ir sąsajos - HDMI prievadų kiekis - 1
Prievadai ir sąsajos - USB 2.0 prievadų kiekis - 2
Prievadai ir sąsajos - Vaizdo įvesties kanalai - 16 kanalų
Prievadai ir sąsajos - VGA (D-Sub) išvesties prievadai - 1
Procesorius - įmontuotas procesorius - Taip
Produkto grynasis svoris - 0.89 kg
Produkto pavadinimas - XVR1B16-I
RJ45 įvesties ir išvesties jungtys - 1
ShortSummaryDescription - Dahua Technology XVR1B16-I, Black, 1920 x 1080 pixels, H.264, H.264+, H.265, H.265+, G.711, PCM, 30 fps, 1920 × 1080, 1280 × 1024, 1280 × 720
Siuntimo dėžės aukštis Siuntimo/pakavimo dėžės matmenys - 31 cm
Siuntimo dėžės gylis Siuntimo/pakavimo dėžės matmenys - 33.5 cm
Siuntimo dėžės plotis Siuntimo/pakavimo dėžės matmenys - 8.5 cm
Siuntimo dėžės svoris Siuntimo/pakavimo dėžės matmenys - 1.43 kg
Spalva - Juoda
Svoris ir matmenys - Aukštis - 47.6 mm
Svoris ir matmenys - Gylis - 231.4 mm
Svoris ir matmenys - Plotis - 260 mm
Svoris ir matmenys - Svoris - 890 g
Tinklas - Ethernet LAN - Taip
Tinklas - Ethernet LAN (RJ-45) prievadai - 1
Tinklas - Ethernet sąsajos tipas - Fast Ethernet
Tinklas - naudotojų skaičius - 128 naudotojas (-ai)
Tinklas - Palaikomi tinklo protokolai - HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search
URL - https://www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/WizSense-Series/I3-Series/Cooper-I-Series/XVR1B16-I
USB 2.0 įvesties ir išvesties jungtys - 2
Veikimas - Analoginio signalo formato sistema - NTSC, PAL
Veikimas - Garso sistema - 2 krypčių
Veikimas - Palaikomi garso formatai - G.711, PCM
Veikimas - Produkto spalva - Juoda
Veikimas - PTZ valdymas - Taip
Veikimas - sertifikavimas - FCC: 15 B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130;
EN 55024
UL: UL 60950-1
Veikimas - Stovo talpa - 1U
Veikimas - Vaizdo judesio aptikimas - Taip
Veikimas - Įdiegta operacinė sistema - Įterptinis LINUX
Vienetai pristatymo dėžėje - 1
Vienetas Apskaičiuotas svoris - 1.43 kg
Vienetas Apskaičiuotas tūris - 0.008827 cubm
Vieneto dėžės aukštis - 0.31
Vieneto dėžės ilgis - 0.335
Vieneto dėžės plotis - 0.085
15pin D-sub Input/Output connectors - 1
Description - "16 Channels Penta-brid 1080N/720P Compact 1U 1HDD WizSense Digital Video Recorder > H.265+/H.265 dual-stream video compression > Supports Full-channel AI-Coding > Supports HDCVI/AHD/TVI/CVBS/IP video inputs > Max 18 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps Incoming Bandwidth > Long transmission distance over coax cable > Up to 8 channels video stream (analog channel) SMD Plus
DVR type - 16 Channel
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -10 - 45 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 90%
Camera Compatibility - HDCVI 1080P/HDCVI 720P
Warranty - 36 months
WarrantyInfo -
Audio-Out Input/Output connectors - 1
Audio-In Input/Output connectors - 1
GTIN - 6939554919299
Hard drive - Maximum HDD capacity - 6 TB
HDMI Input/Output connectors - 1
Category - Digital Video Recorders (DVR)
Category Code - STD
Hard drive - HDD interface - SATA, SATA II, SATA III
Hard drive - Number of HDDs supported - 1
LongDesc - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, Cooper Series featuring SMD Plus to benefit customers from AI upgrade. The series are designated to reduce false-alarm rates and human surveillance costs, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.SMD PlusSMD Plus, referred to as Smart Motion Detection Plus, which is an upgrading version of SMD that greatly improves the alarm accuracy by loading deep-learning algorithm. It analyzes person and vehicle shapes based on motion detection and send alarms only when person and vehicle intrudes.*SMD Plus takes effect when SMD or IVS&SMD is selected in AI Mode.AI CodingCompared with H.265, AI codec can reduce up to 50% bit rate and storage requirements while have no loss of decoding compatibility, providing clear human and vehicle details.Smart H.265+Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras.HDCVI/AHD/TVI/CVBS Auto-detectThe XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient.High Definition Camera InputThe XVR supports up to 1080p HDCVI camera and 6MP IP camera input.Coaxial Audio/Upgrade/AlarmThe integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation.Long Distance TransmissionThe HDCVI system supports long distance transmission over coaxial cable and UTP, max. 700 m for 4K/4MP, 800 m for 1080p and 1200 m for 720p.
LongProductName - 16 channels, BNC, 1080p, RCA, HDMI, VGA, RJ-45, USB 2.0, SATA, DC 12V, 1U, 260x231.4x47.6 mm
LongSummaryDescription - Dahua Technology XVR1B16-I. Product colour: Black, Maximum video resolution: 1920 x 1080 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Video input channels: 16 channels. Ethernet interface type: Fast Ethernet, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm..., Number of users: 128 user(s). HDD interface: SATA, SATA II, SATA III, Maximum HDD capacity: 6 TB. DC voltage: 12 V, Power consumption (typical): 10 W
Power - Power consumption (typical) - 10 W
Power - DC voltage - 12 V
Power supply requirements - 12 VDC, 2 A
Dimensions - 260.0 × 231.4 × 47.6 mm
Model - XVR1B16-I
Performance - Bit rate - 4096 Kbit/s
Performance - Maximum video resolution - 1920 x 1080 pixels
Performance - Video compression formats - H.264, H.264+, H.265, H.265+
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Recorders/Cooper-I-Series/XVR1B16-I
Title - Dahua Technology XVR1B16-I Black
Performance - Playback resolutions supported - 1920 × 1080, 1280 × 1024, 1280 × 720
Performance - Video capturing speed - 30 fps
Performance - Video streaming - Yes
Full Description Line - 16 Channel|Camera Compatibility HDCVI 720P/HDCVI 1080P|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|12 VDC, 2 A|Colour Black
Brand - Dahua Technology
BrandPartCode - DH-XVR1B16-I
Ports & interfaces - BNC input ports - 16
Ports & interfaces - Audio output - 1
Ports & interfaces - Audio input - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - Video input channels - 16 channels
Ports & interfaces - VGA (D-Sub) output ports - 1
Processor - Built-in processor - Yes
Product Net Weight - 0.89 kg
ProductName - XVR1B16-I
RJ45 Input/Output connectors - 1
ShortSummaryDescription - Dahua Technology XVR1B16-I, Black, 1920 x 1080 pixels, H.264, H.264+, H.265, H.265+, G.711, PCM, 30 fps, 1920 × 1080, 1280 × 1024, 1280 × 720
Shipping Box Height Shipping/Package Box Dimensions - 31 cm
Shipping Box Depth Shipping/Package Box Dimensions - 33.5 cm
Shipping Box Width Shipping/Package Box Dimensions - 8.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 1.43 kg
Colour - Black
Weight & dimensions - Height - 47.6 mm
Weight & dimensions - Depth - 231.4 mm
Weight & dimensions - Width - 260 mm
Weight & dimensions - Weight - 890 g
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Ethernet interface type - Fast Ethernet
Network - Number of users - 128 user(s)
Network - Supported network protocols - HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search
URL - https://www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/WizSense-Series/I3-Series/Cooper-I-Series/XVR1B16-I
USB 2.0 Input/Output connectors - 2
Performance - Analog signal format system - NTSC, PAL
Performance - Audio system - 2-way
Performance - Audio formats supported - G.711, PCM
Performance - Product colour - Black
Performance - PTZ control - Yes
Performance - Certification - FCC: 15 B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130;
EN 55024
UL: UL 60950-1
Performance - Rack capacity - 1U
Performance - Video motion detection - Yes
Performance - Operating system installed - Embedded LINUX
Units per Shipping Box - 1
Unit Calculated Weight - 1.43 kg
Unit Calculated Volume - 0.008827 cubm
Unit Box Height - 0.31
Unit Box Length - 0.335
Unit Box Width - 0.085
