Apkrova (maks.) - 800 kg
Aprašymas - Standing installation cabinet 19" 42U 800x1200 black LCD perforated door Lanberg (Flat Pack) The Lanberg FF01-8242-23BL single-section standing cabinet is a solution designed for network construction, cabling and equipment installation in size 19 with a maximum total load capacity of up to 800 kg. It can be used in data centers that require a large amount of space in equipment cabinets. The cabinet will successfully fulfill its role in large, extensive networks and server rooms, both in small, medium and large companies and corporations. It will also work well in low-voltage installations such as cable TV networks, alarm systems, fire protection systems, access control systems as well as CCTV and IP monitoring systems. The construction is made using high quality rolled steel, it is characterized by excellent design and workmanship. The cabinet enables full adjustment of the depth of the vertical mounting rails. It is equipped with a perforated front door with a lock, which can be mounted on the right or left side. It has removable side panels (with locks included) and a rear perforated door with a lock. It is possible to introduce wiring through the lockable upper and lower panels (with plugs in the set). The cabinet has an LCD display mounted on the front, displaying basic information (e.g. temperature inside the cabinet, current time and current status of fans) about the status of the device. The set includes a ventilation panel with 4 fans 230V, equipped with a thermostat. In addition, the set includes accessories for mounting the mounting rails, M6 screws and plugs for entry panels, and thanks to the construction for self-assembly (flat pack), the whole thing is in 3 flat packages, which facilitates transport.
Apsaugos klasė - IP20
Aukštis - 42U
Daiktai - Plieno
ean - 5901969437980
gamintojas - Lanberg
garantija - 36
garantijos_tipas - normalus
Kitos funkcijos - LCD display Floor panel: 4 castors with brakes + adjustable feet Ventilation panel: 4 230V fans in the upper casing and a thermostat included Door type: Front - Perforated, Rear - Perforated, Compliance with standards: ANSI/EIA RS-310D, IEC297-2, DIN41494; PART1 & PART7, ETSI Material: High-quality rolled steel, powder coated Cable openings: Top, Bottom (adjustable)
LCD ekranas - Taip
Matmenys - Cabinet dimensions: 800 x 1200 x 2097.5 mm Height (top panel - bottom panel): 2018.5 mm Height (top panel - ground): 2091.5 mm Height (top panel - ground including screws): 2097.5 mm Internal spacing width between rack rails: 450 mm The width of the spacing between the openings of the rack rails: 465 mm External width between rack rails: 500 mm
matmenų aukštis - 500 mm
matmenų gylis - 930 mm
matmenų plotis - 1900 mm
matmuo svoris - 139000 g
Pavadinimas - CE+WEEE
pavadinimas - Rack cabinet standing 19 -inches 42U 800x1200 black
Plotis - 19 ''
Pridedami priedai - Mounting accessories Front and rear door lock 2 x Side panel locks 20 x M6 screw 2 x Vertical cable organizer
Priekinių durų tipas - Perforuotas
Spalva - Juoda
Spalva - RAL 9004
Svoris - 139 kg
Tipas - Stovimas ant grindų
vendpn - FF01-8242-23BL
Load (max) - 800 kg
Description - Standing installation cabinet 19" 42U 800x1200 black LCD perforated door Lanberg (Flat Pack) The Lanberg FF01-8242-23BL single-section standing cabinet is a solution designed for network construction, cabling and equipment installation in size 19 with a maximum total load capacity of up to 800 kg. It can be used in data centers that require a large amount of space in equipment cabinets. The cabinet will successfully fulfill its role in large, extensive networks and server rooms, both in small, medium and large companies and corporations. It will also work well in low-voltage installations such as cable TV networks, alarm systems, fire protection systems, access control systems as well as CCTV and IP monitoring systems. The construction is made using high quality rolled steel, it is characterized by excellent design and workmanship. The cabinet enables full adjustment of the depth of the vertical mounting rails. It is equipped with a perforated front door with a lock, which can be mounted on the right or left side. It has removable side panels (with locks included) and a rear perforated door with a lock. It is possible to introduce wiring through the lockable upper and lower panels (with plugs in the set). The cabinet has an LCD display mounted on the front, displaying basic information (e.g. temperature inside the cabinet, current time and current status of fans) about the status of the device. The set includes a ventilation panel with 4 fans 230V, equipped with a thermostat. In addition, the set includes accessories for mounting the mounting rails, M6 screws and plugs for entry panels, and thanks to the construction for self-assembly (flat pack), the whole thing is in 3 flat packages, which facilitates transport.
Protection class - IP20
Height - 42U
Stuff - Steel
ean - 5901969437980
producer - Lanberg
guarantee - 36
guarantee_type - normal
Other features - LCD display Floor panel: 4 castors with brakes + adjustable feet Ventilation panel: 4 230V fans in the upper casing and a thermostat included Door type: Front - Perforated, Rear - Perforated, Compliance with standards: ANSI/EIA RS-310D, IEC297-2, DIN41494; PART1 & PART7, ETSI Material: High-quality rolled steel, powder coated Cable openings: Top, Bottom (adjustable)
LCD display - Yes
Dimensions - Cabinet dimensions: 800 x 1200 x 2097.5 mm Height (top panel - bottom panel): 2018.5 mm Height (top panel - ground): 2091.5 mm Height (top panel - ground including screws): 2097.5 mm Internal spacing width between rack rails: 450 mm The width of the spacing between the openings of the rack rails: 465 mm External width between rack rails: 500 mm
dimension height - 500 mm
dimension depth - 930 mm
dimension width - 1900 mm
dimension weight - 139000 g
Designation - CE+WEEE
name - Rack cabinet standing 19 -inches 42U 800x1200 black
Width - 19 ''
Accessories included - Mounting accessories Front and rear door lock 2 x Side panel locks 20 x M6 screw 2 x Vertical cable organizer
Front door type - Perforated
Color - Black
Color - RAL 9004
Weight - 139 kg
Type - Floor standing
vendpn - FF01-8242-23BL
